Generating FastAPI Schema Classes from OpenAPI

What's good about generating the schema classes used by FastAPI from an OpenAPI definition?

• You can verify the design using only the OpenAPI definition
• No need to write the classes in FastAPI by hand

Preparing OpenAPI

We prepare the FastAPI source code and the OpenAPI definition with a layout like this. By the way, the definition file's path is generated/openapi.json because we use openapi-generator to generate openapi.json, and this is a common setup at our company.

project
  L api
    L main.py         : FastAPI's main.py
  L schema
    L generated
      L openapi.json  : OpenAPI definition file

Installing datamodel-code-generator

To generate schema classes from the OpenAPI definition, we use datamodel-code-generator. Run the following command to install it into your python environment.

# Install command
$ pip install datamodel-code-generator
$ datamodel-codegen --version
0.11.19

Outputting schemas.py

Next, run the following command to output the schema file into the FastAPI project.

datamodel-codegen  --input /schema/generated/openapi.json --input-file-type openapi --output api/schemas.py

As an example, running this against the following OpenAPI definition produced python source code like this.

schema/generated/openapi.json

{
  "openapi" : "3.0.3",
  "info" : {
    "title" : "api",
    "version" : "0.0.1"
  },
  "servers" : [ {
    "url" : "/"
  } ],
  "tags" : [ {
    "description" : "index",
    "name" : "index"
  } ],
  "paths" : {
    "/" : {
      "post" : {
        "description" : "POST",
        "operationId" : "IndexPost",
        "requestBody" : {
          "content" : {
            "application/json" : {
              "schema" : {
                "$ref" : "#/components/schemas/IndexPostRequest"
              }
            }
          },
          "description" : "POST",
          "required" : true
        },
        "responses" : {
          "200" : {
            "content" : {
              "application/json" : {
                "schema" : {
                  "$ref" : "#/components/schemas/IndexPostResponse"
                }
              }
            },
            "description" : "OK"
          }
        },
        "tags" : [ "index" ]
      }
    }
  },
  "components" : {
    "schemas" : {
      "IndexPostRequest" : {
        "properties" : {
          "name" : {
            "type" : "string"
          }
        },
        "type" : "object"
      },
      "IndexPostResponse" : {
        "properties" : {
          "hello" : {
            "type" : "string"
          }
        },
        "type" : "object"
      }
    }
  }
}

api/schemas.py

# generated by datamodel-codegen:
#   filename:  openapi.json
#   timestamp: 2022-02-25T07:02:11+00:00

from __future__ import annotations

from typing import Optional

from pydantic import BaseModel

class IndexPostRequest(BaseModel):
    name: Optional[str] = None

class IndexPostResponse(BaseModel):
    hello: Optional[str] = None

Implementing in FastAPI

Let's implement the generated schemas.py in FastAPI. We changed api/main.py as follows.

api/main.py

from FastAPI import FastAPI

from schemas import IndexPostRequest, IndexPostResponse
app = FastAPI()

@app.post("/", response_model=IndexPostResponse)
def read_root(request:IndexPostRequest) -> IndexPostResponse:
    response = IndexPostResponse()
    response.hello = request.name
    return response

Verifying it works

We ran FastAPI locally and executed the following command to check that it behaves as expected.

$ curl -X 'POST' \
  'http://0.0.0.0:8000/' \
  -H 'accept: application/json' \
  -H 'Content-Type: application/json' \
  -d '{
  "name": "World"
}'

{"hello":"World"}

We got the expected value back.

Summary

OpenAPI has such a rich set of class generation tools available, which is really great.
